Description
COMPOSITIONS
| ITEM | VALUE | Test Method |
|---|---|---|
| PVC | ||
| THICKNESS | 0.100 & 0.010mm | ASTM-D-1593 |
| DYNESS (CM) | 37 | ASTM-D-2578 |
| TENSILE STRENGTH (kg/CM2)
MD |
278 246 |
ASTM-D-882A |
| ELONGATION (%)
MD |
186 181 |
ASTM-D-882A |
| DIMENSIONAL STABILITY (%)
MD |
2.6 | ASTM-D-1204 |
| GLUE | ||
| TYPE | Gray, pressure sensitive solvent based, Acrylic type | |
| THICKNESS (mm) | 0.030 & 0.005mm | |
| INITIAL TACK (Ball No) | No. 14 | J.DOW METHOD |
| COHESION, HOLDING POWER (Hr) (2cm X 2cm X 1kg, @25&C) |
>48 hr | PSTC-7 |
| ADHESION (kg/inch) 70C/7days (180 peel adhesion to Stainless) | 1.0kg/inch | PSTC-1 |
| LINER | ||
| TYPE | KRAFT PAPER | |
| THICKNESS (mm) | 0.140 & 0.010mm | |
| COLOR | WHITE | |
| BASE WEIGHT | 120gsm Liner paper single side PE | |
| SHELF LIFE | ||
| 1 YEAR | STORAGE AT +5C TO +40C AND 35~75% RELATIVE HUMIDITY WITHOUT PRINTING AND IN ORIGINAL PACKING BOX | |
| DURABILITY | ||
| 1 YEAR | WITHOUT LAMINATION AND USING CERTIFIED INKS | |
REMARK:
THE ABOVE INFORMATION IS GIVEN IN GOOD FAITH AND FOR GUIDENCE ONLY. ALL DATA WILL BE CHANGED BY DIFFERENT TESTING CONDITIONS.
Conclusions and Announcements
Declaration by Desert Sign: Please choose DS products suitably according to relative provisions or industrial standards. DS bears the responsibility for the specified technical and performance data on this page only. DS is not responsible for any other liability. (The technical data on this page is calculated on average, and 5% tolerance is acceptable)
